Winning the Red Spot Design Award
IF Design Award
Left and Right Tightening Mechanism
Wave wheel arc lock
Collision avoidance design
Box Handle + Lifting Lock
Self-hanging upper and lower lock, single-person assembly,
save time and labor.
Store hardware program and correction data on each module;
Read back at any time to facilitate customer use and maintenance.
品番 | CS3.91(Indoor) |
ピクセルピッチ | 3.91mm |
LED | SMD2020 |
ドット密度 | 65536pixel/㎡ |
輝度 | 800-1000nits |
色温度 | 6500-9500k |
ドライブモード | 1/16 |
パネルサイズ(W×H×D) | 500mm×500mm×707mm / 19.68"×19.68"×27.83" |
パネル解像度 | (127×127)/2pixel |
パネル重量 | 3.8kg/8.37lb |
パネル材質 | Die casting aluminum |
最大消費電力 | ≦650w/㎡ |
平均消費電力 | ≦325w/㎡ |
視野角 | H:160º V:140º |
リフレッシュレート | 3840Hz |
カラー階調処理 | 14-16bit |
防護レベル | IP30 |
動作湿度 | 10%-60%RH |
動作温度 | -20℃~+45℃ |
最大スタック | 10m |
最大吊り下げ | 10m |
曲面設置(可選択) | -15°/-12.5°/-10°/-7.5°/-5°/-2.5°/0°/2.5°/5°/7.5°/10°/12.5°/15° |
寿命 | 50,000 hrs |
保管温度/湿度 | -40℃~+60℃;10%-60%RH |
